Description
The Von Duprin CDRX35AL-DT-06 is a Grade 1 panic exit device designed for single and double doors with mullion. UL listed and ANSI A156.3 compliant, it solves emergency egress requirements for commercial facilities while offering a smooth mechanism case and non-handed installation flexibility.
This rim exit device fits doors 4 feet 2.8 inches to 4 feet wide and installs 39.8 inches from finished floor. Compatible with wood and metal doors, it includes sex bolts for secure fastening. Contact E.D. Locks as your authorized Von Duprin dealer for expert sizing, finishing options, and installation support at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Von Duprin
- Model: CDRX35AL-DT-06
- Finish: 26D (Satin Chrome)
- Handing: RHR (Right Hand Reverse)
- Grade: ANSI A156.3 2014 Grade 1
- UL Listed: Panic exit hardware
- Device Length: 2 feet 4 inches to 3 feet (711 mm to 914 mm)
- Door Width: 4 feet 2.8 inches to 4 feet (864 mm to 1219 mm)
- Device Centerline Height: 39.8 inches (1011 mm)
- Center Case Dimensions: 8.2 inches x 1.6 inches x 2.4 inches (208 mm x 40 mm x 62 mm)
- Mechanism Case Dimensions: 2.25 inches x 2.25 inches (57 mm x 57 mm)
- Pushbar Projection (Neutral): 3.8 inches (97 mm)
- Pushbar Projection (Depressed): 3.1 inches (78 mm)
- Latch Bolt: Deadlocking, 0.75 inch (19 mm) throw
- Fasteners: Sex bolts (SNB) 1.75 inches to 2.25 inches for wood and metal doors
- Case Type: Smooth mechanism case
- Non-Handed: Except when signal switch option used
