Description
Stanley Security's CECSFBB179-66 electrified hinge delivers power and reliability to high-traffic commercial doors. This full mortise, five-knuckle concealed switch hinge is engineered for architects and facility managers who need seamless access control integration without visible wiring on the door face.
The 4.5" by 4.5" steel hinge supports standard-weight doors and includes six dedicated wires for electrified strike or locking systems. Left-hand orientation suits most commercial applications. As an authorized Stanley Security dealer, E.D. Locks provides expert specification assistance and free technical support at sales@edlocks.com or 1-877-207-6067 to ensure correct installation and keying.
Specifications
- Brand: Stanley Security
- Model: CECSFBB179-66
- Handing: Left Hand (LH)
- Size: 4.5" x 4.5"
- Corner Style: Square Corner
- Material: Steel
- Weight Class: Standard Weight
- Mounting: Full Mortise
- Knuckles: Five
- Bearing Type: Ball Bearing
- Switch Type: Concealed
- Conductor: Concealed
- Finish: Dark Oxidized Satin Bronze Oil Rubbed
- Wires: Spec. 6
