Description
The Yale 8800 Series mortise lock delivers ANSI/BHMA Grade 1 security for demanding commercial applications. This heavy-duty lock features a reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible handing that simplifies installation on doors 1-3/4" to 3-1/4" thick. Ideal for offices, schools, hospitals and high-traffic facilities.
The CRR8824FL 606 comes standard with a 6-pin brass cylinder, two keys, and a curved lip strike for 1-3/4" doors. UL/cUL fire-rated up to 3 hours and windstorm certified. As an authorized Yale dealer, E.D. Locks provides expert consultation, finish selection guidance, and fast shipping. Contact sales@edlocks.com or 1-877-207-6067 for custom configurations or keying assistance.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, up to 3-1/4" available
- Cylinder: 6-pin brass, keyed-random with two keys; 7-pin available
- Strike: 1-1/4" curved lip for 1-3/4" doors standard; reversible
- Field Reversible: Yes
- Warranty: 10 years mechanical
- Available Finishes: 17 options
