Description
The Arrow DCN516-3 is a heavy-duty surface-mounted door closer engineered for high-traffic institutional and commercial applications. Its rugged cast iron body, hardened steel rack and pinion, and high-tensile springs deliver reliable performance in demanding environments. The non-handed design accommodates regular, top jamb, and parallel arm mounting, making it versatile for diverse installation scenarios.
This model features a parallel arm with stop and thumb-turn hold-open capability, ideal for doors opening 90-110 degrees. Adjustable for spring sizes 1-6, it works on doors up to 1-3/4" thick and includes all necessary hardware. UL/cUL and UL10C listed for code compliance. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert sizing, finish selection, and installation guidance from an authorized Arrow dealer.
Specifications
- Brand: Arrow
- Model: DCN516-3
- Series: DCN500 Heavy Duty
- Finish: Aluminum (689)
- Mount Type: Non-handed (regular, top jamb, parallel arm)
- Arm Type: Heavy-duty parallel arm with stop and thumb-turn hold open
- Door Opening Range: 90-110 degrees
- Spring Sizes: Adjustable 1-6
- Door Thickness: Up to 1-3/4"
- Body: Cast iron
- Rack and Pinion: Hardened steel
- Springs: High-tensile steel
- Temperature Rating: All temperature fluid
- Cover: Full plastic standard
- Hardware Included: Fully threaded self-reaming/tapping screws, machine nuts, thru-bolts
- Certifications: UL/cUL listed, UL10C listed for positive pressure (UBC-72 1997)
- Standards: ANSI A156.4, ANSI ICC A117.1
- Warranty: 10-year limited
- Packaging: One per box, four boxes per carton
