Description
The Corbin Russwin DL2212 605 is a Grade 2 certified cylindrical deadlock featuring a solid steel deadbolt with hardened, free-spinning steel pin insert and 1-inch throw. Ideal for commercial and institutional doors, it delivers reliable security and easy installation for applications requiring ANSI 156.5 compliance without premium cost.
Ships standard for 1-3/4-inch door thickness with 2-3/4-inch backset and brass front. The 6-pin L4 keyway comes 0-bitted with two nickel silver keys; master keying and security cylinders are available. As an authorized Corbin Russwin dealer, E.D. Locks provides expert specification assistance at sales@edlocks.com or 1-877-207-6067 to ensure correct handing, keying, and finish selection for your application.
Specifications
- ANSI/BHMA Grade 2 certified to 156.5 standards
- Deadbolt: 1 inch throw, solid steel with hardened free-spinning pin insert
- Standard door thickness: 1-3/4 inch (44mm)
- Standard backset: 2-3/4 inch (70mm); optional 2-3/8 inch (60mm)
- Front: 2-1/4 inch (57mm) x 1-1/8 inch (29mm), brass or stainless steel standard
- Cylinder: 6-pin L4 keyway, 0-bitted, brass standard
- Strike: 2-3/4 inch (70mm) x 1-1/8 inch (29mm)
- Handing: Non-handed
- Keys: Two nickel silver standard
- Optional features: Security cylinder, master keying, construction master keying, visual and concealed key control, alternate door thicknesses and backsets
- Warranty: One-year limited
