Description
The DormaKaba E-Plex 5000 is an extra heavy-duty electronic mortise lock with deadbolt, designed for facilities requiring keyless access control and audit capability. It features Winston levers, supports up to 100 access codes, and records 3,000 audit events. Built with solid cast housings and levers, it handles demanding indoor and outdoor door applications.
This mortise lock is non-handed and field-adjustable, compatible with standard door frames using 2 3/4" backsets and 3/4" or 1" deadbolts. Keying is managed through the Kaba 90 keyway system with KIL (Key-In-Lever) capability. Contact E.D. Locks for integration support, installation guidance, and warranty assistance at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: DormaKaba
- Model: E5067XKWL-626-41
- Lock Type: Electronic Mortise Lock with Deadbolt
- Lever Style: Winston
- Access Codes: 100
- Audit Events: 3,000
- Keyway: Kaba 90
- Key-In-Lever: Yes (KIL)
- Finish: Satin Chrome
- Backset (Mortise): 2 3/4" (70 mm)
- Latch Options: 3/4" (19 mm) or 1" (25 mm) deadbolt
- Handing: Non-handed, field-adjustable
- Construction: Extra heavy-duty cylindrical lockset, solid cast housings and levers
