Description
The Von Duprin E7500 is a 24V electric lock designed for institutional and commercial doors where fire code compliance and controlled access are critical. It locks the outside trim while keeping the door latched, preserving fire ratings and enabling mechanical override via the outside cylinder for emergency egress.
Compatible with TP, K, or L function options. The E7500 includes two SPDT signal switches to monitor trim and latch bolt status. As an authorized Von Duprin dealer, E.D. Locks provides expert configuration guidance and support at sales@edlocks.com or 1-877-207-6067 to ensure proper installation and code compliance.
Specifications
- Voltage: 24V
- Finish: Stainless Steel (US10B)
- Signal switches: Two SPDT
- Available functions: TP, K, L
- Latch bolt control: Motorized with mechanical override
