Description
The Falcon H2101PD DANE 626 is a Grade 1 interconnected entrance lock designed for commercial and institutional applications requiring coordinated deadbolt and latch control. The satin chrome finish and Dane lever handle provide durability and a professional appearance. This lock solves the security challenge of managing both latch and deadbolt operation from a single keyway, ideal for high-traffic entry doors.
Compatible with 1-3/8" to 1-3/4" thick doors and field reversible for either hand. Standard 2-3/4" backset with optional 2-3/8" available. UL Listed for 1-1/2 Hour B Label fire rating. As an authorized Falcon dealer, E.D. Locks provides expert guidance on hand specification, keying options, and strike selection. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility assistance and to ensure correct installation.
Specifications
- Brand: Falcon
- Model: H2101PD DANE 626
- Grade: 1
- Type: Interconnected Entrance Lock with Indicator
- Finish: Satin Chrome
- Lever: Dane
- Door Thickness: 1-3/8" to 1-3/4"
- Backset: 2-3/4" standard, 2-3/8" available
- Latch Projection: 1/2"
- Deadbolt Projection: 1" with 1/4" hardened steel security roller
- Standard Latchface (2-3/4" backset): 2-1/4" x 1-1/8"
- Standard Latchface (2-3/8" backset): 2-1/4" x 1"
- Cylinders: Drilled 6 chambers, pinned in 5 (6 chamber pinning available)
- Standard Keyway: G (standard cylinders), A (I/C core cylinders)
- Trim Material: Wrought brass, bronze, or stainless steel roses; brass, bronze, or stainless steel knobs
- Strikes Included: (1) 2-3/4" x 1-1/8" T-strike and (1) 2-3/4" x 1-1/8" lipless strike
- Mechanism: Cold formed steel, zinc plated and dichromated
- Handing: Field reversible
- Certification: UL Listed 1-1/2 Hour B Label
