Description
The Yale 8800 Series mortise lock trim pack is a heavy-duty commercial lock designed for maximum security and durability. Built for offices, schools, hospitals and institutional buildings, it features a reinforced stainless steel deadbolt, vandal-resistant trim, and ANSI/BHMA Grade 1 certification to withstand years of demanding use.
This trim pack fits standard 1-3/4" doors and is field-reversible for left or right-hand installation. The 8800 Series is UL/cUL fire-rated up to 3 hours and windstorm certified. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and installation. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA A156.13 Series 1000, Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard (up to 3-1/4" available)
- Bevel front: free-floating, adjusts flat to 1/8" standard bevel
- Cylinder: 6-pin brass, keyed-random with two keys standard
- Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" doors (reversible)
- Available in 17 finishes
- 10-year mechanical warranty
