Description
The Yale 8800 Series mortise lock trim pack is engineered for commercial doors requiring ANSI/BHMA Grade 1 security and durability. This complete trim assembly features a reinforced stainless steel deadbolt, vandal-resistant hardware, and field-reversible handing, solving the need for reliable access control in high-traffic and demanding environments.
Compatible with 1-3/4" standard door thickness and adjustable up to 3-1/4". Installation is straightforward with quick lever handing and standard nonhanded strike. As an authorized Yale dealer, E.D. Locks provides expert guidance on finish selection, keying options, and special-order configurations. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard, to 3-1/4" thick doors to order
- Front: Bevel front, free-floating adjustment from flat to 1/8" standard bevel
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Reversibility: Field reversible
- Strike: 1-1/4" curved lip for 1-3/4" door (other lengths available)
- Finishes: 17 options available
- Warranty: 10 year mechanical
- Mechanism: Stainless steel
- Windstorm: Certified
