Description
The Aiphone JPS-4AEDF is a professional 4x8 color video intercom system featuring a 7-inch touchscreen master station and matching handset. Designed for multi-unit residential and commercial buildings, it delivers hands-free communication via VOX technology or traditional handset operation, solving the need for secure, visual visitor verification and tenant communication.
This system operates on 24V DC power and supports up to 1,000 call recordings with SD/SDHC card storage. Installation requires 2-conductor wiring from door station to master (up to 330 feet) and CAT-5e/6 cabling for network connectivity. An authorized E.D. Locks dealer can guide you through system design and compatibility with door release relays. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for expert installation support and genuine Aiphone components.
Specifications
- Power: 24V DC (PS-2420UL power supply required)
- Master Station Display: 7-inch color LCD touchscreen
- Camera: 1/4-inch color CMOS, 100 degrees vertical x 170 degrees horizontal
- Video Recording: Up to 20 calls internally; up to 1,000 calls on SD/SDHC card
- Communication: Hands-free (VOX) or full-duplex handset
- Door Release: N/O dry contact, 24V AC/DC, 500mA
- Wiring Door Station to Master: 2-conductor, non-shielded (up to 330 feet)
- Wiring Master to Distribution Adaptor: CAT-5e or CAT-6 (up to 650 feet)
- Distribution Adaptor to Sub Master: CAT-5e or CAT-6 (up to 165 feet)
- Power Supply Distance: 16 feet (22AWG) or 33 feet (18AWG)
