Description
The Schlage L9010 02A 619 is an extra heavy-duty mortise lock built for high-traffic institutional environments including schools, hospitals, and factories. This ANSI Grade 1 certified lock combines durability with dependable operation, featuring a fully wrapped steel case, all-metal zinc dichromate-plated parts, and anti-friction design to handle constant daily use and abuse.
The L9010 supports ten functions in one universal case and is field-reversible without opening the lock. It works with standard mortise lock preparation and accepts Schlage cylinders and trim options. For expert assistance selecting the right configuration, keying options, or installation guidance, contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067.
Specifications
- Brand: Schlage
- Model: L9010 02A 619
- Type: Extra Heavy Duty Mortise Lock
- Security Rating: ANSI Grade 1
- Case Construction: Heavy-gauge, fully wrapped steel
- Working Parts: All-metal, zinc dichromate-plated
- Functions: Universal case, ten functions available
- Special Features: Break-away spindle, hub blocking plate, fail secure mode, locking thumb-turn, independent lever rotation, field-reversible handing, floating mounting tabs
- Finish: Satin Chrome (619)
