Description
The Schlage L9070H is an extra heavy-duty mortise lock built for high-traffic commercial environments like schools, hospitals, and factories. This ANSI Grade 1 certified lock features a fully wrapped steel case, zinc dichromate-plated components, and anti-friction design to withstand constant daily use and abuse without compromising security or operation.
The L9070H offers universal 10-function capability in a single case with field-reversible handing, making installation flexible across beveled doors and retrofit applications. As an authorized Schlage dealer, E.D. Locks provides expert guidance on keying, function selection, and compatibility. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for personalized support and to verify finish and function options for your project.
Specifications
- Brand: Schlage
- Model: L9070H 03B 630AM
- Grade: ANSI Grade 1
- Type: Mortise Lock, Heavy Duty
- Case: Fully wrapped steel with heavy gauge construction
- Finish: 630AM (Satin Stainless Steel)
- Functions: Universal 10 functions in one case
- Handing: Field-reversible without opening lock case
- Security Features: Break-away spindle, hub blocking plate, spring-loaded fusible link (fail secure)
- Installation: Thru-bolted trim, floating mounting tabs, external spring cages for retrofit
- Interior: Screwless shank mounting, locking thumb-turn, independent lever rotation
