Description
The Von Duprin LD33ANL-OP 4 26D is a UL-listed panic exit device designed for single and double doors with or without mullions. Built to ANSI A156.3 Grade 1 standards, it provides reliable emergency egress for commercial facilities, schools, hospitals, and high-traffic venues where life safety compliance is non-negotiable.
This rim-mounted device fits door sizes from 2'4" to 4' and accepts a range of electric monitoring and latch retraction options to match your access control needs. The non-handed design simplifies inventory management. E.D. Locks is an authorized Von Duprin dealer; contact our experts at sales@edlocks.com or 1-877-207-6067 for specification verification, finish selection, and installation support.
Specifications
- Brand: Von Duprin
- Model: LD33ANL-OP 4 26D
- Standard: ANSI A156.3 Grade 1, UL Listed
- Door Compatibility: 2'4" to 4' single and double doors with mullion
- Case Finish: Grooved (33A model)
- Latch Bolt: Deadlocking, 3/4" throw
- Device Centerline: 39 13/16" from finished floor
- Center Case Dimensions: 8 3/16" x 2 13/32" x 1 9/16"
- Mechanism Case Dimensions: 2 1/4" x 2 1/4"
- Pushbar Projection: 3 13/16" neutral, 3 1/16" depressed
- Dogging: Hex key standard; CD cylinder or LD options available
- Electric Options: LX latchbolt monitor, RX pushpad monitor, RX2 double pushpad monitor, SS signal switch, EL electric latch retraction, ALK alarm kit
- Strike: 1439 Dull Black
- Sex Bolts: 1 3/4" to 2 1/4" for wood and metal doors
