Description
The Von Duprin LD75L-07 is a narrow stile exit device designed for warehouses, industrial facilities, offices, multifamily buildings, and retail spaces. ANSI/BHMA Grade 1 certified, it delivers reliable egress control with field-sizeable lengths for single and double door applications, available in rim or concealed vertical rod styles.
This device accepts multiple exit trim models and functions to match your specific code and aesthetic needs. As an authorized Von Duprin dealer, E.D. Locks provides expert guidance on certification requirements, trim selection, and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility verification and fast, secure ordering.
Specifications
- Model: LD75L-07 4 628
- Brand: Von Duprin
- Finish: Anodized Aluminum (628)
- Certifications: ANSI/BHMA A156.3 Grade 1, ANSI/UL 10C (fire rated), ANSI/UL 305, CAN/ULC-S104 (fire rated), CAN/ULC-S132
- Available Lengths: 3 feet and 4 feet, field sizeable
- Device Types: Rim or Concealed Vertical Rods (CVR)
- Compatible Trim Models: 360, 374, 376, 386, 388
- Available Functions: Exit Only, Dummy Trim, Lever, Lever with Blank Escutcheon, Night Latch, Turn Lever variants
- Available Finishes: Bright Brass, Satin Brass, Satin Bronze, Satin Nickel, Bright Chrome, Satin Chrome, Anodized Aluminum, Satin Stainless Steel, Aged Bronze, Duranodic Dark Bronze, Matte Black
