Description
The Schlage LV9040 02L 626 is an extra heavy-duty mortise lock engineered for high-traffic institutional environments including schools, hospitals, and factories. Built to ANSI Grade 1 standards, this lock combines robust security with dependable operation under constant use, solving the need for durable hardware that resists door edge attacks and manipulation.
This universal lock case supports ten functions in one body and accepts Schlage L-Series trim with field-reversible handing, simplifying retrofit projects. Compatible with standard mortise applications and beveled doors. As an authorized Schlage dealer, E.D. Locks provides expert configuration guidance and keying support. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for assistance selecting the right function and finish for your project.
Specifications
- Grade: ANSI Grade 1
- Lock Type: Mortise, Extra Heavy Duty
- Case Material: Heavy-gauge steel with zinc dichromate plating
- Functions: Ten available in universal case
- Security Features: Break-away spindle, hub blocking plate, spring-loaded fusible link (fail secure)
- Handing: Field-reversible without opening case
- Door Compatibility: Beveled and standard doors
- Trim Mount: Screwless shank mounting, thru-bolted trim
