Description
The Securitron M38LS is a 600 lb holding force electromagnetic lock designed for traffic control in secured or monitored high-traffic areas. Ideal for interior rooms, closets and hallways, it delivers reliability and low maintenance with automatic dual-voltage operation and no field adjustment required.
Installation is quick with bracket mounting and wiring chamber design. The instant release circuit eliminates residual magnetism for safety. As an authorized Securitron dealer, E.D. Locks provides expert guidance on compatibility and setup. Contact sales@edlocks.com or call 1-877-207-6067 for technical assistance and to confirm your door frame specifications.
Specifications
- Holding Force: 600 lbs (272 kg)
- Magnalock Dimensions: 10-1/2"L x 1-11/16"D x 2-1/2"H
- Strike Dimensions: 6-1/4"L x 1/2"D x 1-5/8"H
- Electrical: 350 mA at 12 VDC, 170 mA at 24 VDC
- Operating Temperature: +32 to +110F (0 to +43C)
- Indoor use only
- All ferrous surfaces plated for rust resistance
