Description
The Securitron M82 is a heavy-duty electromagnetic lock delivering 1800 lbs of holding force for high-security interior, perimeter, and exterior access control. Built for high-risk environments, it combines unsurpassed magnetic strength with weatherproof sealed construction and rust-resistant plating on all ferrous surfaces, ensuring long-term durability even in harsh conditions.
Compatible with standard door frame mounting using collapsing blind nuts for maximum strength. The M82 features automatic dual-voltage operation (12 or 24 VDC), instant release with no residual magnetism, and includes 10 ft of jacketed cable with noise suppression. As an authorized Securitron dealer, E.D. Locks provides expert installation guidance and free technical support at sales@edlocks.com or 1-877-207-6067.
Specifications
- Holding Force: 1800 lbs (816 kg)
- Magnalock Dimensions: 12"L x 1-3/4"D x 3"H
- Strike Dimensions: 9"L x 1/2"D x 2-3/4"H
- Cable: 10 ft jacketed, stranded conductor
- Electrical: 350 mA at 12 VDC, 200 mA at 24 VDC
- Operating Temperature: -40 to +140°F (-40 to +60°C)
- Features: Dual-voltage, instant release, noise suppression, weatherproof sealed, rust-resistant
- Applications: Indoor and outdoor use
