Description
The Falcon MA911B 630 is a commercial mortise lock engineered for high-traffic office, hospital, and education environments. Its interchangeable core design allows quick re-keying without removing the lock, while the two-piece stainless steel latch and saw-resistant roller deadbolt deliver reliable security and durability through constant daily use.
This lock accommodates standard door thicknesses of 1-3/8" to 2-1/2" with a 2-3/4" backset and is reversible for either-hand installation. It meets ANSI/BHMA Series 1000 and earns a 3-hour UL label. Contact our authorized dealer specialists at sales@edlocks.com or 1-877-207-6067 for keying, compatibility, and installation guidance.
Specifications
- Brand: Falcon
- Model: MA911B 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5/6/7-pin standard or 6/7-pin interchangeable core
- Keyways: "G" (standard cylinder) or "A" (I/C cylinder)
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified Functions: 12 or 24 VDC available
- Standards: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Includes: Two nickel silver keys
