Description
The Falcon MA911L 630 is a commercial mortise lock built for high-traffic office, hospital, and education environments. Its interchangeable core design enables quick re-keying without removing the lock from the door, and it's compatible with SFIC products. The MA Series combines dependable security with affordability and durability.
This lock fits standard door thicknesses from 1-3/8" to 2-1/2" and features a 2-3/4" backset. Contact E.D. Locks, an authorized Falcon dealer, at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying options, handing, cylinder pins, and installation to ensure the right fit for your project.
Specifications
- Brand: Falcon (by Allegion)
- Model: MA911L
- Finish: 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw with two 13/16" hardened steel saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway standard; A keyway on I/C cylinder
- Handing: Right hand standard; left hand optional, reversible in field
- Electrified: Available in 12 or 24 VDC
- Standard Keys: Two nickel silver keys included
- ANSI/BHMA: Series 1000 compliance
- UL Rating: 3 hour A label
