Description
The Falcon MA921CP6 630 mortise lock is a heavy-duty commercial lock designed for offices, hospitals, educational facilities, and other institutional environments requiring reliable security and durability. Built to withstand constant use, this ANSI/BHMA Series 1000 lock features a mechanical anti-friction latch bolt, saw-resistant roller deadbolt, and interchangeable core (SFIC) compatibility for simple re-keying without removing the lock.
The MA921CP6 accommodates standard door thicknesses of 1-3/8" to 2-1/2" and is reversible for both right-hand and left-hand applications. Backed by Allegion, an industry leader, and available in multiple finishes and electrified options (12/24 VDC). Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for expert guidance on keying, finish selection, and installation to ensure optimal security performance.
Specifications
- Brand: Falcon
- Model: MA921CP6 630
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin standard; 6 or 7-pin interchangeable core
- Latch Bolt: Two-piece stainless steel, mechanical anti-friction, 3/4" projection
- Dead Bolt: 1" throw stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel, adjustable for door bevel
- Keying: Two nickel silver keys standard; "G" keyway standard cylinder, "A" keyway IC cylinder
- Electrified: Available 12 or 24 VDC
- ANSI/BHMA: Meets 156.13, Series 1000
- UL: 3 hour A label
- Handing: Right hand standard, left hand optional, reversible in field
