Description
The Falcon MA931L 630 is a heavy-duty mortise lock built for commercial environments including offices, hospitals, and educational facilities. This ANSI Series 1000 lock combines affordability with proven durability, featuring a two-piece stainless steel latch bolt, 1-inch deadbolt with saw-resistant rollers, and cold-formed steel case rated for constant daily use without failure.
The MA931L accommodates standard door thickness of 1-3/8" to 2-1/2" with a 2-3/4" backset and offers an interchangeable core (SFIC) for quick re-keying. Right-hand handing is standard; left-hand and field-reversible options are available. Choose from 12 or 24 VDC electrified functions or mechanical operation. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, finishes, and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6567 for personalized support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4" only
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Deadbolt: 1" throw, stainless steel with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Cylinders: Solid brass, 5/6/7-pin standard or interchangeable core options
- Keyways: G keyway (standard cylinder), A keyway (I/C cylinder)
- Electrified Functions: 12 or 24 VDC available
- Rating: ANSI/BHMA 156.13 Series 1000, UL 3-hour A label
- Handing: Right-hand standard, left-hand optional, field-reversible
