Description
The Falcon MA941L 605 is a heavy-duty mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. It combines security with durability, featuring a two-piece stainless steel latch bolt, a 1-inch throw dead bolt with saw-resistant rollers, and an interchangeable core for quick re-keying without removing the lock from the door.
This lock accommodates door thicknesses from 1-3/8 to 2-1/2 inches and meets ANSI/BHMA 156.13 Series 1000 and UL 3-hour A label standards. It's compatible with SFIC products from other manufacturers and available in 12 or 24 VDC electrified functions. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying options, handing, and installation. Contact our team at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- Brand: Falcon
- Model: MA941L 605
- Door Thickness: 1-3/8 to 2-1/2 inches
- Backset: 2-3/4 inches only
- Case: Cold formed steel, zinc dichromate plated, 0.090 inches thick
- Latch Bolt: Two-piece stainless steel, 3/4 inch projection
- Dead Bolt: 1 inch throw, stainless steel with hardened steel, saw-resistant rollers
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6 or 7-pin standard; 6 or 7-pin interchangeable core
- Keyways: G keyway standard; A keyway on I.C. cylinder
- Faceplate: 1-1/4 by 8 inches, brass or stainless steel
- Handing: Right hand standard; left hand optional, reversible
- ANSI/BHMA: Meets 156.13, Series 1000
- UL Rating: 3 hour A label
- Electrified Functions: Available 12 or 24 VDC
