Description
The Sargent MD8673G-24V is a 24-volt electric exit device built for high-traffic commercial and institutional doors. Engineered to exceed ANSI/BHMA Grade 1 standards, this rim-mounted device delivers durable security with minimal maintenance, ideal for facilities requiring reliable emergency egress hardware that performs throughout the building's life.
Designed for metal doors 1-3/4" minimum thickness, this device accepts modular rail configurations (E, F, J, or G) to fit door widths from 24" to 48". The 24V electric option supports delayed egress, monitoring, latch retraction, and alarm functions. As an authorized Sargent dealer, E.D. Locks provides expert configuration assistance and free shipping on orders over $450. Contact sales@edlocks.com or 1-877-207-6067 for keying options and application support.
Specifications
- Brand: Sargent
- Model: MD8673G-24V
- Configuration: Rim-mounted, RHR (right-hand reverse)
- Voltage: 24V electric
- Door Types: Metal, 1-3/4" to 2-1/4" thick
- Minimum Stile Width: 4-1/2"
- Device Centerline: 41" standard (38" for accessibility)
- Center Case Dimensions: 8-3/8" x 2-5/8"
- Pushbar Projection: 3" neutral, 2-1/8" depressed
- Rail Options: E (24-32"), F (33-36"), J (37-42"), G (43-48")
- Strikes: 650 top, 606 bottom
- Standards: Exceeds ANSI/BHMA Grade 1
