Description
The Sargent 80 Series exit device is a heavy-duty panic hardware solution for metal doors requiring Grade 1 security and reliability. Ideal for commercial buildings, schools, and facilities needing code-compliant egress, this rim-mounted device exceeds ANSI/BHMA standards with modular construction and minimal moving parts for maintenance-free operation.
This right-hand reverse model fits 1-3/4" minimum metal doors and includes a 4-1/2" stile width requirement. Choose from E, F, J, or G rails based on your door width (24" to 48"), factory-cut to size. Contact E.D. Locks at sales@edlocks.com or 1-877-207-6067 for keying, electric options (alarm, beacon, photoluminescent, delayed egress, latch monitoring), and installation support from an authorized Sargent dealer.
Specifications
- Brand: Sargent
- Model: MD8674G-12V ETE RHR 32D
- Type: Rim Exit Device, Right-Hand Reverse
- Door Thickness: 1-3/4" minimum (up to 2-1/4" with specification)
- Minimum Stile Width: 4-1/2"
- Rail Options: E (24-32"), F (33-36"), J (37-42"), G (43-48") door widths
- Standard Strikes: 650 Top, 606 Bottom (panic and fire-rated)
- Device Centerline Height: 41" standard, 38" for accessibility
- Pushbar Projection: 3" neutral, 2-1/8" depressed
- Center Case: 8-3/8" x 2-5/8"
- Top Bolt: Stainless steel
- Max Door Height: 96" (HC and WS options)
- Certification: Exceeds ANSI/BHMA Grade 1
- Optional Features: Dogging, alarm, beacon, photoluminescent, illuminated touchpad, latch monitoring, remote retraction, delayed egress, electric dogging
