Description
The Arrow MLX11-SR-BSP-IC is a Grade 2 cylindrical lockset designed for commercial door applications requiring reliable security and durability. Its free wheeling lever provides abuse resistance, making it ideal for high-traffic environments where doors experience frequent, forceful operation. This lockset solves the need for quick, dependable upgrades to existing door hardware.
Installation requires a standard 2-1/8" bore and fits doors 1-3/8" to 1-3/4" thick with a 2-3/4" backset. The stainless steel latch is UL listed with a 1/2" throw and guarded latchbolt. Compatible with Arrow AR and Schlage CS keyways. As an authorized E.D. Locks dealer, we provide expert support at sales@edlocks.com or 1-877-207-6067 to ensure proper keying and installation for your application.
Specifications
- Grade 2 cylindrical lockset
- Door bore: 2-1/8" (53.97mm)
- Backset: 2-3/4" (69.85mm)
- Door thickness: 1-3/8" to 1-3/4" (34.93mm to 44.45mm)
- Latch: Stainless steel, 1/2" (12.7mm) throw, UL listed
- Latch front: 1-1/8" x 2-1/4"
- Lever material: Pressure cast zinc, 4-3/4" (120.65mm) length
- Rose material: Wrought brass, 3-11/32" (84.8mm) diameter
- Total door projection: 2-17/32" (64.5mm)
- Cylinder: Solid brass, 6 pin
- Keyway: Arrow AR and Schlage CS
- Keys included: 2 brass keys
- Strike: 4-7/8" ANSI (123.83mm)
- Handing: Non-handed
- Warranty: 10 years mechanical
- Packaging: 6 per case
