Description
The Yale 8800 Series mortise lock trim pack is a Grade 1 commercial-duty solution for offices, hospitals, and institutional buildings requiring ANSI/BHMA certified security. Its reinforced stainless steel deadbolt, field-reversible latchbolt, and vandal-resistant trim deliver uncompromising strength in applications up to 3-hour fire-rated openings.
This trim pack fits standard 1-3/4" doors and installs with quick lever handing and a nonhanded strike. The 6-pin keyed-random cylinder ships with two keys. As an authorized Yale dealer, E.D. Locks offers expert specification help and fast shipping. Contact sales@edlocks.com or call 1-877-207-6067 for handing options, finish selection, or custom backset configurations.
Specifications
- ANSI/BHMA A156.13 Grade 1 Certified
- UL/cUL Fire Rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard; up to 3-1/4" available
- Cylinders: 6-pin keyed-random (7-pin available)
- Strike: 1-1/4" curved lip for 1-3/4" door (reversible)
- Field Reversible: Yes
- Finishes: 17 available
- Warranty: 10 years mechanical
