Description
The Yale 8800 Series mortise lock is a Grade 1 commercial-duty solution for interior and exterior doors in offices, hotels, and multi-tenant buildings. Its reinforced stainless steel deadbolt, vandal-resistant trim, and field-reversible design solve the need for reliable, easy-to-install security without compromise on strength or durability.
This trim pack fits standard 1-3/4" doors and works with Yale's modular cylinder and strike options for flexible configurations. As an authorized E.D. Locks dealer, we provide expert guidance on keying, handing, and finish selection. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for personalized help matching this lock to your door and application requirements.
Specifications
- ANSI/BHMA Grade 1, Series 1000
- UL/cUL fire rated up to 3 hours
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard (up to 3-1/4" to order)
- Mechanism: Stainless steel
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strikes: 1-1/4" curved lip for 1-3/4" door (other lengths to order)
- Field reversible handing
- Available in 17 finishes
- 10 year mechanical warranty
