Description
The Yale 8800 Series mortise lock trim pack is built for commercial doors demanding uncompromising strength and durability. Featuring a reinforced stainless steel deadbolt, heavy-duty vandal-resistant trim, and ANSI/BHMA Grade 1 certification, this lock solves security and longevity concerns in high-traffic facilities, offices, and institutional settings.
Quick lever handing and field-reversible latchbolt simplify installation on 1-3/4" standard doors (up to 3-1/4" available). Includes 6-pin keyed-random cylinder with two keys. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, handing, and compatibility. Contact sales@edlocks.com or 1-877-207-6067 for personalized assistance and a 10-year mechanical warranty.
Specifications
- ANSI/BHMA A156.13 Series 1000, Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Stainless steel mechanism and 3/4" latchbolt throw
- Backset: 2-3/4"
- Door thickness: 1-3/4" standard (up to 3-1/4" to order)
- Field reversible handing
- 1-1/4" curved lip strike for 1-3/4" doors (standard)
- Bevel front, free-floating (flat to 1/8" standard bevel)
- 6-pin brass cylinder, keyed-random, two keys included (7-pin available)
- Available in 17 finishes
- 10-year mechanical warranty
