Description
The Yale 8800 Series MOR8865FL mortise lock trim pack is a Grade 1 commercial-duty solution for facilities requiring uncompromising strength and security. Heavy-duty stainless steel construction with reinforced deadbolt and vandal-resistant trim addresses the toughest commercial applications, from office buildings to hospitals.
This trim pack fits standard 1-3/4" doors and features field-reversible handing for flexible installation. Yale's authorized dealers like E.D. Locks provide expert guidance on keying, backset options, and finish selection. Contact our team at sales@edlocks.com or 1-877-207-6067 for technical questions and fast shipping on all Yale commercial hardware.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- UL/cUL Fire Rating: Up to 3 hours
- Windstorm Certified: Yes (local codes apply)
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (up to 3-1/4" to order)
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available)
- Strikes: 1-1/4" curved lip for 1-3/4" door (reversible)
- Finishes: 17 available finishes
- Warranty: 10 years mechanical
- Field Reversible Handing: Yes
