Description
The Schlage ND Series ND53BD is a Grade 1 cylindrical lockset engineered for commercial facilities including healthcare, education, government, offices and retail spaces. It delivers 3+ million operating cycles without failure, providing lasting security and reliability for any institutional environment.
This RHO lever lock accommodates standard door thicknesses from 1 5/8" to 2 1/8" with a 2 3/4" backset and includes 6-pin Everest 29 keyway with two keys per lock. The lock supports master keying, interchangeable cores, and wire-wireless access control integration. As an authorized Schlage dealer, E.D. Locks offers expert configuration assistance at sales@edlocks.com or 1-877-207-6067 to ensure proper installation and keying for your facility.
Specifications
- Brand: Schlage
- Model: ND53BD RHO 626
- Grade: 1 (ANSI certified)
- Operating cycles: 3+ million
- Door thickness: 1 5/8" to 2 1/8" (41-54mm) standard
- Backset: 2 3/4" (70mm) standard; optional 2 3/8", 3 3/4", 5"
- Latch bolt: Steel, 1/2" throw, deadlocking
- Faceplate: 1 1/8" x 2 1/4" (29mm x 57mm) square corner, beveled
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys per lock: 2 nickel silver
- Handing: Non-handed
- Keying options: Master keying, grand master keying, construction keying, interchangeable core, Primus high security
- Warranty: 10-year limited
