Description
The Schlage ND80JD is a Grade 1 cylindrical lockset engineered for commercial facilities including healthcare, education, government, office and retail environments. This non-handed lock delivers proven reliability, extensive keying options, and wire-wireless access control capabilities to meet modern security and operational needs.
Built for standard 1 5/8" to 2 1/8" doors with 2 3/4" backset, the ND80JD features a 6-pin Everest 29 keyway, 1/2" steel latch bolt, and brass faceplate in a satin stainless finish (630). It supports master keying, interchangeable cores, and Primus high-security cylinders. As an authorized Schlage dealer, E.D. Locks provides expert product matching and installation guidance. Contact sales@edlocks.com or call 1-877-207-6067 for free technical support.
Specifications
- Brand: Schlage
- Model: ND80JD HSLR
- Finish: 630 (Satin Stainless Steel)
- Handing: RH (Right Hand, Non-Handed)
- Door Thickness: 1 5/8" to 2 1/8" standard
- Backset: 2 3/4" standard; 2 3/8", 3 3/4", 5" optional
- Latch Bolt: Steel, 1/2" throw, deadlocking
- Faceplate: 1 1/8" x 2 1/4", square corner, beveled
- Cylinder: 6-pin Everest 29 S123 keyway
- Keys: Two patented nickel silver keys per lock
- Keying Options: Master keying, grand master keying, construction keying, interchangeable core, Primus high-security
- Strike: ANSI curved lip 1 1/4" x 4 7/8" x 1 3/16" standard
- Grade: Grade 1, 3+ million cycle rating
- Warranty: Ten-year limited
