Description
The Yale 8800 Series mortise lock trim pack is a Grade 1 commercial lock designed for high-security interior and exterior doors. Heavy-duty stainless steel construction, field-reversible latchbolt, and vandal-resistant trim make this ideal for busy commercial buildings, hospitals, schools, and offices requiring reliable access control and durability.
This trim pack fits standard 1-3/4" doors and features a 2-3/4" backrest with 3/4" stainless steel throw. Installation is straightforward with quick lever handing and a standard nonhanded strike. As an authorized Yale dealer, E.D. Locks provides expert product selection and after-sale support at sales@edlocks.com or 1-877-207-6067 to ensure proper keying and compatibility.
Specifications
- ANSI/BHMA Grade 1 certified
- UL/cUL fire rated up to 3 hours
- Windstorm certified
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door thickness: 1-3/4" standard (up to 3-1/4" available to order)
- Cylinders: Brass, 6-pin keyed-random with two keys (7-pin available to order)
- Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" doors (other lengths to order)
- Available in 17 finishes
- 10-year mechanical warranty
