Description
The Yale 8800 Series PNR8860FL is a commercial-grade mortise lock built for high-traffic doors in offices, schools, and institutional buildings. Its reinforced stainless steel deadbolt and ANSI/BHMA Grade 1 certification deliver exceptional durability and security where strength matters most.
This lock fits standard 1-3/4" doors and features field-reversible handing for flexible installation on either hand. As an authorized Yale dealer, E.D. Locks offers expert guidance on finish selection, keying options, and compatibility with your existing hardware. Contact our specialists at sales@edlocks.com or 1-877-207-6067 for personalized support.
Specifications
- ANSI/BHMA Certification: A156.13, Series 1000, Operational Grade 1
- Fire Rating: UL/cUL rated up to 3 hours
- Mechanism: Stainless steel
- Backset: 2-3/4"
- Latchbolt: 3/4" stainless steel throw
- Door Thickness: 1-3/4" standard (accommodates up to 3-1/4" to order)
- Front: Bevel front, free-floating, adjusts flat to 1/8" bevel
- Cylinder: Brass, 6-pin, keyed-random with two keys (7-pin available)
- Reversibility: Field reversible handing
- Strike: 1-1/4" curved lip for 1-3/4" door (other sizes to order)
- Finishes: 17 commercial options available
- Warranty: 10 years mechanical
