Description
The Von Duprin QEL3327AEO is a Grade 1 panic exit device designed for single and double doors in commercial buildings. It features a grooved mechanism case, deadlocking anti-friction latches, and surface-mounted vertical rods. This UL-listed device meets ANSI A156.3-2008 standards and solves fire code compliance and emergency egress requirements for offices, retail, and institutional facilities.
Compatible with standard door frames and available in multiple configurations for doors 3 feet to 4 feet wide. Installation requires proper alignment of vertical rods and latch bolts; extension rods are available for taller doors. As an authorized Von Duprin dealer, E.D. Locks provides expert selection and installation guidance. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility verification and free shipping on orders over $450.
Specifications
- Brand: Von Duprin
- Model: QEL3327AEO 3 26D
- Grade: ANSI A156.3-2008 Grade 1
- UL Listed: Yes
- Mechanism Case: Grooved, 8 13/16 x 2 13/32 x 1 9/16 inches
- Case Dimensions: 2 1/4 x 2 1/4 inches
- Pushbar Projection (Neutral): 3 13/16 inches
- Pushbar Projection (Depressed): 3 1/16 inches
- Latch Bolt: Deadlocking anti-friction, 5/8 inch throw
- Vertical Rods: 1/2 inch square tubing, standard 7 feet (top rod 34 15/16 inches, bottom rod 31 1/4 inches)
- Top and Bottom Latch: 4 1/2 x 2 1/8 x 1 1/2 inches
- Extension Rods: 1 foot or 3 feet available for doors over 7 feet
- One Piece Top Rod: Available for 8 to 10 foot doors
- Door Undercut: 1/4 inch
- Centerline from Floor: 39 13/16 inches
- Fasteners: #425 SNB standard (1 3/4 to 2 1/4 inches) for wood and metal doors
