Description
The Arrow RL11-BRR-BSP is a cylindrical lockset designed for multi-family housing and light commercial applications. This economical lock features cold rolled steel construction with zinc dichromate finish for corrosion resistance, a guarded latchbolt, and removable through bolts. It solves the need for affordable, durable entry security across diverse residential and commercial properties.
This lock fits standard 2-1/8 inch bore doors, 1-3/8 to 1-3/4 inches thick, and accommodates 2-3/8 or 2-3/4 inch backsets. It comes keyed with two brass keys and includes your choice of ANSI, T-strike, or full lip strike options. As an authorized Arrow dealer, E.D. Locks provides expert guidance on keying, installation, and product selection. Contact sales@edlocks.com or call 1-877-207-6067 for assistance.
Specifications
- Brand: Arrow
- Model: RL11-BRR-BSP
- Lock Type: Cylindrical
- Material: Cold rolled steel with zinc dichromate finish
- Door Bore: 2-1/8 inch standard
- Backset Options: 2-3/8 inch or 2-3/4 inch
- Door Thickness: 1-3/8 to 1-3/4 inches
- Latch: Brass, 1/2 inch throw, UL Listed, guarded latchbolt
- Latch Front 2-3/8 inch: 1 x 2-1/4 inch
- Latch Front 2-3/4 inch: 1-1/8 x 2-1/4 inch
- Trim: Pressure cast zinc levers, 4-3/4 inch length; wrought brass roses, 3-3/8 inch diameter
- Total Projection: 2-1/2 inches from face of door
- Strike Options: 4-7/8 inch ANSI, 2-3/4 inch T-strike, or 2-1/4 inch full lip strike
- Cylinder: Solid brass, 6 pin
- Keyway: Arrow A standard; Schlage CS and competitive keyways available
- Keys Included: 2 brass keys
- Handing: Non-handed
- Features: Removable through-bolts
- Warranty: Five year mechanical
- Packaging: 10 per case
