Description
The Arrow RL17 is a heavy-duty cylindrical lockset designed for multi-family housing and light commercial doors. This economical lock features a brass latch with half-inch throw and UL-listed guarded latchbolt, cold-rolled steel construction with zinc dichromate finish, and removable through-bolts for easy installation and master keying flexibility.
Compatible with standard 2-1/8-inch door bores and fits 1-3/8-inch to 1-4-inch thick doors with 2-3/8-inch or 2-3/4-inch backset options. Comes keyed with 2 brass keys and includes your choice of ANSI, T-strike, or full-lip strike. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for keying options, handing assistance, and expert installation guidance.
Specifications
- Brand: Arrow
- Model: RL17-SR-BSP-CS
- Door Bore: 2-1/8 inch standard
- Backset: 2-3/8 inch or 2-3/4 inch
- Door Thickness: 1-3/8 inch to 1-3/4 inch
- Latch: Brass, 1/2 inch throw, UL Listed guarded
- Latch Front: 1 inch x 2-1/4 inch (2-3/8 inch backset) or 1-1/8 inch x 2-1/4 inch (2-3/4 inch backset)
- Trim: RL pressure cast zinc levers, 4-3/4 inch length; wrought brass roses, 3-3/8 inch diameter
- Total Projection: 2-1/2 inch from face of door
- Strike Options: 4-7/8 inch ANSI, 2-3/4 inch T strike, or 2-1/4 inch full lip strike
- Cylinder: Solid brass, 6 pin
- Keyway: Arrow A standard, Schlage CS and competitive keyways available
- Keys Included: 2 brass keys
- Handing: Non-handed
- Thru-bolts: Removable standard
- Case Quantity: 10 per case
- Warranty: Five year mechanical
