Description
The Von Duprin RX3327AEO is a Grade 1 panic exit device designed for single and double doors in commercial buildings, schools, hospitals, and other high-traffic facilities. This UL-listed, ANSI A156.3-2008 certified device provides reliable emergency egress with a grooved mechanism case and deadlocking anti-friction bolts top and bottom, meeting life safety code requirements.
The RX3327AEO fits doors 2 feet to 4 feet wide with a standard 39 13/16-inch centerline from finished floor. Installation requires standard wood or metal door preparation; extension rods accommodate doors up to 10 feet tall. As an authorized Von Duprin dealer, E.D. Locks provides expert guidance on specifications, keying options, and trim compatibility. Contact sales@edlocks.com or call 1-877-207-6067 for application assistance.
Specifications
- Grade: ANSI A156.3-2008 Grade 1
- Door Width Range: 2 feet to 4 feet (610mm to 1219mm)
- Centerline Height: 39 13/16 inches (1006mm) from finished floor
- Center Case: 8 13/16 x 2 13/32 x 1 9/16 inches (208 x 62 x 40mm)
- Mechanism Case: 2 1/4 x 2 1/4 inches (57 x 57mm)
- Pushbar Neutral Projection: 3 13/16 inches (97mm)
- Pushbar Depressed Projection: 3 1/16 inches (78mm)
- Latch Bolt Throw: 5/8 inch (16mm)
- Door Undercut: 1/4 inch (7mm)
- Top and Bottom Latch: 4 1/2 x 2 1/8 x 1 1/2 inches (114 x 54 x 38mm)
- Vertical Rods: 1/2 inch square tubing, standard 7-foot doors
- Top Rod Length (Standard): 34 15/16 inches (887mm)
- Bottom Rod Length (Standard): 31 1/4 inches (794mm)
- Extension Rods: 1 foot (205mm) or 3 feet (914mm) available for doors over 7 feet
- One Piece Top Rod: Available for 8 to 10-foot doors (2438 to 3048mm)
- Finish: US26 Satin Chrome
- Function: Exit Only (EO)
