Description
The Von Duprin RX35AEO 3 is a UL-listed panic exit device designed for single and double doors with mullions. Grade 1 ANSI A156.3-2014 certified, this rim-mounted hardware provides reliable emergency egress for commercial facilities, schools, and institutional buildings where code-compliant panic hardware is required.
Compatible with doors 28 to 48 inches wide, the RX35AEO 3 features a deadlocking latch bolt and smooth mechanism case. Installation requires standard wood or metal door prep. As an authorized Von Duprin dealer, E.D. Locks provides expert specification assistance and fast shipping. Contact our team at sales@edlocks.com or 1-877-207-6067 for finish options, keying, and installation support.
Specifications
- Brand: Von Duprin
- Model: RX35AEO 3 US15
- Grade: ANSI A156.3-2014 Grade 1
- Device Length: 2'4" to 3'
- Door Width: 2'10" to 4'
- Mounting Height: 39 13/16" from finished floor
- Center Case Dimensions: 8 3/16" x 1 9/16" x 2 13/32"
- Mechanism Case: 2 1/4" x 2 1/4"
- Pushbar Projection (Neutral): 3 13/16"
- Pushbar Projection (Depressed): 3 1/16"
- Latch Bolt: Deadlocking, 3/4" throw
- Non-handed (except with signal switch option)
- UL Listed for panic exit hardware
