Description
The Schlage L9091EU is a Grade 1 wired electrified mortise lock engineered for new construction and high-traffic commercial environments. Built for continuous hardwired power operation, it integrates seamlessly into access control systems for high-security areas, government buildings, and facilities requiring remote access switching and reliable daily performance.
This lock fits standard 1-3/4 inch doors and accommodates optional thicknesses from 1-3/8 to 2-1/2 inches. For keying options, compatibility verification, and expert guidance on your specific installation, contact our authorized dealer team at sales@edlocks.com or call 1-877-207-6067 to ensure proper configuration for your application.
Specifications
- Case Material: CRS with zinc dichromate plating
- Case Size: 4-7/16" x 6-1/16" x 1" (113 mm x 154 mm x 25 mm)
- Standard Door Thickness: 1-3/4" (44 mm)
- Optional Door Thickness: 1-3/8" (35 mm) to 2-1/2" (64 mm)
- Knob or Lever to Cylinder: 3-7/8" (98 mm)
- Knob or Lever to Thumbturn Hub: 2-11/16" (68 mm)
