Description
The Securitron V2M1290DB is a 1200 lbs holding force magnetic lock built for interior and perimeter security doors. Dual voltage operation (12/24VDC, field selectable) makes it flexible for various installations. This lock solves retrofit challenges for facilities upgrading from Locknetics 390+ maglocks, with a specialized mounting plate that uses existing holes and eliminates costly reinstallation.
The V2M1290DB comes with door position switch and bond sensor included. Its plug-in connectors and wire access chamber simplify field wiring. As an authorized Securitron dealer, E.D. Locks offers expert guidance on voltage selection, mounting, and keying. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for compatibility verification and installation support.
Specifications
- Holding Force: 1200 lbs (544 kg)
- Voltage: 12 or 24VDC (field selectable)
- Current Draw: 520mA at 12VDC, 260mA at 24VDC
- Operating Temperature: +32 to +110F (0 to +43C)
- Dimensions: 10-15/32" x 2-27/32" x 1-37/64" (266mm x 72mm x 40mm)
- Finish: Brushed Aluminum
- Features: Door Position Switch, Bond Sensor, UL Listed, Instant Release, One-year Warranty
- Application: Direct retrofit for Locknetics 390+ maglocks
