Description
The Falcon T301S LAT 626 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic and heavy-abuse applications. Non-handed design with removable cylinder for quick re-keying makes retrofitting buildings simple. Compression spring construction exceeds ANSI/BHMA Grade 1 testing requirements, delivering durability and reliability at a solid price point.
Fits standard 1-3/4" to 2-1/8" doors with 2-3/4" backset (2-3/8" also available). Brass and stainless steel components resist rust. Drilled with 6-pin chambers, pinned in 5 (6 or 7-pin options available). As an authorized Falcon dealer, E.D. Locks provides expert guidance on handing, keying, and trim selection. Contact sales@edlocks.com or call 1-877-207-6067 for application support.
Specifications
- Grade: ANSI/BHMA Grade 1
- Type: Extra heavy-duty cylindrical lock
- Handing: Non-handed
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter available)
- Backset: 2-3/4" standard, 2-3/8" available
- Bolt Projection: 9/16" standard (3/4" available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners
- Strike: 4-7/8" x 1-1/4" ANSI with curved lip
- Cylinder: 6-pin chambers, pinned in 5 (6 or 7-pin options)
- Keyway: G keyway standard
- Materials: Brass and cold formed steel (zinc plated, dichromated), stainless steel springs, phosphor bronze cylinder springs
- Cylinder Housing: Solid brass
- Keys: Two nickel silver keys furnished standard
- Interchangeable Core: SFIC and large format available
- Attachment: Through-bolted with (2) 10-32 screws
