Description
The Falcon T411BD D 613 is an extra heavy-duty Grade 1 cylindrical lock engineered for high-traffic institutional and commercial applications. Built with a compression spring that exceeds ANSI/BHMA Grade 1 testing requirements, this lock delivers reliable security and durability in demanding environments where abuse and constant use are expected.
This lock accepts any manufacturer's cylinder and features removable cylinders for quick re-keying without door modification. Standard door thickness accommodates 1-3/4" to 2-1/8"; adapters and backset options are available for custom installations. As an authorized Falcon dealer, E.D. Locks provides expert guidance on configuration and installation. Contact us at sales@edlocks.com or 1-877-207-6067 for assistance selecting the right setup for your project.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/8" to 2-1/8" standard (thin door adapter kit A30775-000-00 available)
- Backset: 2-3/4" standard; 2-3/8" available; 5" backset with link A22161-005-10
- Bolt Projection: 9/16" standard; 3/4" projection available
- Latch Faceplate: 2-1/4" x 1-1/8" square corners standard
- Cylinders: 6-pin chambers, pinned in 5 (6-chamber or 7-pin available); removable for re-keying
- Keyways: G keyway standard on conventional cylinders; A keyway on interchangeable core cylinders
- Cylinder Material: Brass housings and plugs; phosphor bronze springs
- Trim Material: Heavy wrought brass or bronze roses; pressure cast levers
- Keys: Two nickel silver keys furnished standard
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip to ANSI A115.2 standard
- Interchangeable Core: Available in small format (SFIC) and large format
- Handing: Non-handed
