Description
The Falcon T511BD is an extra heavy-duty Grade 1 cylindrical lock built for high-traffic and heavy-abuse institutional applications. It features a compression spring that exceeds ANSI/BHMA Grade 1 testing requirements, brass and stainless steel construction with zinc plating for rust resistance, and a removable cylinder for quick re-keying. Perfect for retrofitting existing buildings and high-use facilities.
This lock accommodates standard 1-3/4" to 2-1/8" door thickness (thin door adapters available), includes a 9/16" bolt projection with UL-listed latch, and comes with two nickel silver keys. Available with conventional 6-pin or interchangeable core cylinders in multiple keyways. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for assistance with specification, keying, and installation guidance.
Specifications
- Grade: ANSI/BHMA Grade 1
- Door Thickness: 1-3/4" to 2-1/8" standard (thin door adapter kit A30775-000-00 available)
- Backset: 2-3/4" standard (2-3/8" available; 5" available with link A22161-005-10)
- Bolt Projection: 9/16" standard (3/4" available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners standard
- Cylinders: 6-pin chambers pinned in 5 (6-chamber or 7-pin available); removable for re-keying
- Cylinder Housing Material: Solid brass with phosphor bronze springs
- Keys: Two nickel silver keys standard
- Keyways: "G" keyway standard on conventional cylinders; "A" keyway standard on I/C core cylinders
- Trim: Heavy wrought brass or bronze roses with pressure cast levers
- Mechanism: Brass or cold formed steel parts, zinc plated and dichromated; stainless steel springs
- Attachment: Threaded mounting nuts; through-bolted with (2) 10-32 screws
- Handing: Non-handed
- Strike: 4-7/8" x 1-1/4" ANSI strike with curved lip
- Interchangeable Core: Available in small format (SFIC) and large format
