Description
The Falcon T561BD Q 625 is an extra heavy-duty Grade 1 cylindrical lock built for high-traffic institutional and commercial doors. Non-handed design with removable cylinders for fast re-keying makes retrofitting and maintenance simple. Compression spring construction exceeds ANSI/BHMA Grade 1 testing, delivering reliable security at a solid price point.
Standard 2-3/4" backset fits 1-3/4" to 2-1/8" door thickness; thin-door adapters available. Accepts any manufacturer's cylinder in 5 or 6-pin configuration; interchangeable core options (SFIC/large format) also available. As an authorized Falcon dealer, E.D. Locks provides expert specification guidance and fast shipping. Contact sales@edlocks.com or 1-877-207-6067 for help matching your door prep.
Specifications
- Grade: ANSI/BHMA Grade 1
- Backset: 2-3/4" standard (2-3/8" available; 5" with link A22161-005-10)
- Door Thickness: 1-3/4" to 2-1/8" standard (thin-door adapter A30775-000-00 available)
- Cylinder: 6-pin chambers, pinned in 5 (6 or 7-pin available)
- Keyway: G keyway standard (A keyway standard on I/C cores)
- Bolt Projection: 9/16" standard (3/4" available)
- Latch Faceplate: 2-1/4" x 1-1/8" with square corners
- Strike: 4-7/8" x 1-1/4" ANSI strike
- Material: Brass or zinc-plated cold-formed steel; stainless steel springs
- Non-Handed: Yes
- Keys Furnished: Two nickel silver keys standard
