The Falcon TP50S S 625 is a mortise lock built for high-traffic commercial environments including offices, hospitals, and educational facilities. This MA Series lock combines robust security with dependable performance, featuring an interchangeable core for quick re-keying and compatibility with SFIC products from other manufacturers.
The lock accommodates standard door thickness of 1-3/8" to 2-1/2" with a 2-3/4" backset. Right-hand handing is standard; left-hand and field-reversible options available. As an authorized Falcon dealer, E.D. Locks provides expert guidance on keying, finish selection, and installation. Contact our sales team at sales@edlocks.com or 1-877-207-6067 for technical support.
Specifications
- Door Thickness: 1-3/8" to 2-1/2"
- Backset: 2-3/4"
- Case: Cold formed steel, zinc dichromate plated, 0.090" thick
- Hubs: Hardened steel
- Cylinders: Solid brass, 5, 6, or 7-pin available
- Latch Bolt: Two-piece stainless steel, 3/4" projection
- Dead Bolt: 1" throw with saw-resistant rollers
- Faceplates: 1-1/4" x 8" brass or stainless steel
- Electrified: 12 or 24 VDC available
- ANSI/BHMA: Series 1000
- UL: 3 hour A label
