Description
The Yale 3000 Series architectural door closer combines reliability, appearance and durability for commercial and institutional applications. Its cast aluminum body, rack and pinion design, and staked valves deliver consistent performance across adjustable spring sizes 1-6, solving the need for a versatile closer that handles virtually any mounting challenge.
This non-handed closer accepts regular arm, top jamb and parallel arm configurations, making it compatible with most door types. Separate latch, sweep and backcheck valves allow precise adjustment for your specific needs. Contact our authorized dealer team at sales@edlocks.com or 1-877-207-6067 for expert guidance on finish selection, sizing and installation support.
Specifications
- Cast aluminum body
- Adjustable spring sizes 1 through 6
- Tri-packed mounting options (regular arm, top jamb, parallel arm)
- Non-handed design
- Staked valves with rack and pinion design
- 1-1/4" (32mm) diameter piston
- 5/8" (16mm) diameter pinion journals
- Separate latch, sweep and backcheck intensity valves
- 2-1/8" (54mm) projection with standard covers
