Description
Yale's 3000 Series architectural surface door closer combines reliability, durability, and clean design for commercial and institutional applications. This non-handed closer suits virtually any door configuration, offering adjustable spring sizes 1 through 6, independent latch and sweep control, and a rack-and-pinion mechanism that delivers consistent performance in high-traffic environments.
The 3000 Series arrives tri-packed with regular arm, top jamb, and parallel arm mounting options for flexible installation. It features a cast aluminum body with staked valves and self-drilling screws for simplified setup. Our authorized dealer team at E.D. Locks can help you select the right spring size, finish, and arm configuration for your project. Contact sales@edlocks.com or call 1-877-207-6067 for expert guidance.
Specifications
- Piston diameter: 1-1/4 inch (32mm)
- Pinion journal diameter: 5/8 inch (16mm)
- Standard cover projection: 2-1/8 inch (54mm)
- Spring sizes: 1 through 6 (adjustable)
- Body material: Cast aluminum
- Design: Rack and pinion with staked valves
- Mounting: Non-handed; tri-packed (regular arm, top jamb, parallel arm)
- Valve control: Separate latch, sweep, and backcheck intensity
