Description
The Yale 3000 Series J3511 is an architectural surface-mounted door closer engineered for commercial and institutional buildings requiring reliable, adjustable closing action. Its cast aluminum body, rack and pinion design, and independent valve controls solve the challenge of finding a heavy-duty closer that handles diverse door sizes and traffic patterns without frequent maintenance.
This closer accommodates standard, top jamb, and parallel arm mounting configurations, making it non-handed and versatile across most door frames. Spring sizes 1-6 allow field adjustment to match your specific door weight and closing speed. Verify arm type and cover finish against your door prep before ordering. As an authorized Yale dealer, E.D. Locks provides expert guidance on selection and installation. Contact us at sales@edlocks.com or 1-877-207-6067 for application support.
Specifications
- Brand: Yale/Accentra
- Model: J3511
- Mounting: Surface (tri-packed with regular arm, top jamb and parallel arm options)
- Non-handed design
- Adjustable spring sizes: 1 through 6
- Piston diameter: 1-1/4" (32mm)
- Pinion journal diameter: 5/8" (16mm)
- Standard projection: 2-1/8" (54mm)
- Valve type: Staked valves with independent latch, sweep and backcheck intensity controls
- Body material: Cast aluminum
- Drive mechanism: Rack and pinion
