Description
The Falcon W301S Q 605 is a commercial cylindrical lock designed for lower-traffic doorways in government, retail, industrial, and multi-family buildings. This affordable lock features a conventional cylinder with small-format interchangeable core compatibility, making it ideal for facilities requiring flexible keying and re-keying without door removal.
The W301S fits standard 1-3/8" to 1-3/4" door thickness with a 2-3/4" backset and accepts cylinders from Falcon, Schlage, Corbin-Russwin, Yale, and Sargent. Master keying is available on Falcon and Schlage C keyways. As an authorized Falcon dealer, E.D. Locks provides expert guidance on specification, installation, and keying solutions. Contact our team at sales@edlocks.com or 1-877-207-6067 for application support.
Specifications
- Door Thickness: 1-3/8" to 1-3/4" standard
- Backset: 2-3/4" standard; 2-3/8" also available
- Mechanism: Brass or cold-formed steel, zinc plated and dichromated; stainless steel springs
- Cylinder: 6-pin conventional or 6- or 7-pin interchangeable core, solid brass housing
- Keyways: G (standard), A (I/C core), Schlage C (optional)
- Bolt Projection: 1/2" stainless steel, UL listed for 3-hour door assemblies
- Latch Faces: 1" x 2-1/4" (2-3/8" backset) or 1-1/8" x 2-1/4" (2-3/4" backset)
- Strike: 4-7/8" x 1-1/4" ANSI with curved lip
- Trim: Heavy wrought brass or bronze roses; pressure-cast zinc levers
- Handing: Non-handed
- Keys: Two nickel silver keys standard
